The CLASS CROP TIGER 30 TERRA TRAC Combine Harvester has revolutionised mechanised rice harvesting.
This compact and light combine harvester designed with reliable rubber tracks is best for rice paddies.
As well as making harvesting fast and easy, the CLASS CROP TIGER 30 TERRA TRAC Combine Harvester delivers superior grain quality and negligible losses.
CLASS CROP TIGER 30 TERRA TRAC Combine Harvester Specs Price Overview
If you have no idea about the CLASS CROP TIGER 30 TERRA TRAC Combine Harvester Price in India, Technical all parts Specifications, Key Features, Images and review video, then you are at the right place, cause here you can get everything which you need to know about it.
ALSO SEE:
CLASS CROP TIGER 30 TERRA TRAC Combine Harvester Price in India
Price: Rs. 19 Lakh.
CLASS CROP TIGER 30 TERRA TRAC Combine Harvester Key Features
- TANGENTIAL AXIAL FLOW (TAF) is unequalled for harvesting versatility - wheat, rice, maize, basmati, sunflowers, soybeans, chickpeas, mustard, mung beans, pigeon peas, etc.
- The compact design and low weight make for good manoeuvrability in small fields
- Uniform weight distribution and maximum pulling power thanks to the TERRA TRAC system
- Protected drives help extend the service life of the systems in tough working conditions
- The large 1200-litre grain tank enables long working days with minimal interruptions for offloading
CLASS CROP TIGER 30 TERRA TRAC Combine Harvester Specifications
| Cutter-bar | |
| Effective width | 2100 (7) mm (ft.) |
| Threshing system | |
| Threshing principle | TANGENTIAL AXIAL FLOW (TAF) |
| Threshing and separating rotor of 450 mm diameter, threshing width 560 mm, separating width 1240 mm |
|
| Threshing rotor speed | 500 - 1282 rpm |
| Rotor speed adjustment | Pulley change |
| Unloading system | Universal joint type with speed unloading (20 l/s) |
| Track type | Full rubber CLAAS/Bridgestone tracks, suitable for wet lands |
| Crop cleaning | |
| Cleaning sieve area | 1.24 (upper and lower sieves) |
| Cleaning system | Forced air-cleaning fan, 2 speeds,1200 and 1500 rpm, controlled by fan shutter |
| Grain tank | |
| Capacity | 1200 l |
| Engine | |
| Manufacturer | TATA |
| Emission Class | BSII |
| Model | 4SP RTV |
| Cylinders / displacement no. / ccu | 4 cylinder, 4 stroke, water-cooled |
| Maximum power | 60 hp |
| Rated engine speed | 2800 rpm |
| Fuel tank capacity | 100 l |
| Dimensions | |
| Length (including cutterbar) | 5855 mm |
| Height | 2905 mm |
| Width | 2620 mm |
| Ground clearance body frame | 380 mm |
| Ground clearance hydraulic motor | 240 mm |
| Weights | |
| Machine weight | 4270 kg |
CLASS CROP TIGER 30 TERRA TRAC Combine Harvester Video
So this was all about the CLASS CROP TIGER 30 TERRA TRAC Combine Harvester, I hope you got all the information about this small tractor and also that you enjoyed reading this article, but if you have any questions regarding this article, then please comment for us, we will solve your problem as soon. thanks for visiting our site.
